Licensing optiClient Attendant
8.5.2 optiClient Attendant V7.0 Connected to HiPath 3000 < V5.0
Licensing is performed on the optiClient Attendant. In order to ensure unique licensing, the li-
cense file is linked with the MAC address of the CLA PC.
Procedure
Figure 8-4 Procedure for Licensing optiClient Attendant V7.0 on HiPath 3000 < V5.0
Step Activity (Remarks)
1. Install optiClient Attendant, CLM and CLA (if not yet available).
Enter the IP address and port number of the CLA in the optiClient Attendant config-
uration manager.
2. Read out the MAC address of the CLA PC (via the CLM).
3. Enter the LAC and MAC address at the CLS in order to generate the license key either
● a) via CLM/CLS communication,
or
● b) via direct communication with the CLS via a web browser.
4. Transfer the license key from the CLS via the CLM to the CLA either
● a) via CLM/CLS communication,
or
● b) manually on the CLM (license key is already available, offline activation).
HiPath 3000
< V5.0
(CLS)
CLM
V.24,
USB or
TCP/IP
CLA
1
5
2
3
4
optiClient At-
tendant 1
CLC
optiClient At-
tendant 6
CLC
