Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-28 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
4.2.4.4 Grounding the System
Ground the system as described.
Grounding: Inspection and Implementation
Preliminary Inspection of the 19-Inch Cabinet:
Is the 19-inch cabinet grounded
by a separate ground conduc-
tor (green/yellow)?
The 19-inch cabinet must be grounded by a sepa-
rate ground conductor (green/yellow).
Danger
If your personnel are not qualified to work on the
low-voltage network (230 Vac), you must hire a li-
censed electrician to install the ground.
Does the 19-inch cabinet have
a potential equalization bus at
which the HiPath 3800 can be
grounded as shown in Figure 4-
13 ?
A potential equalization bus must be installed in
the 19-inch cabinet and connected to the ground
conductor.
Danger
If your personnel are not qualified to work on the
low-voltage network (230 Vac), you must hire a li-
censed electrician to install the ground.
If you answer “Yes” to both questions, the system (system cabinets, patch panels) may be
grounded as described below.
7
Danger
Each HiPath 3800 system cabinet and any patch panel (S30807-K6143-X) that may
be installed must be grounded as shown in Figure 4-13 by a separate ground con-
ductor (minimum cross-section = 2.5 mm
2
). Make sure that the ground conductor is
securely installed and strain-relieved.
If external factors can impact on the ground conductor and if protected installation is
not possible, the ground conductor must have a minimum cross-section of 4 mm
2
.
Please note:
The 19-inch cabinet’s potential equalization bus may only be used if it is grounded
by a separate ground conductor.
Failure to follow these instructions can result in electrical shock.
NO
YES
NO
YES
To Next Page
