Siemens Hipath 5000 - Figure 3-137 TS2 (Not for U.S.) - Interfaces (S30810-Q2913-X100, -X300); Figure 3-138 TS2 R (Not for U.S.) - Interfaces (S30810-K2913-Z100, -Z300)

boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-331
Boards for HiPath 3000
Peripheral Boards
TS2 interfaces
TS2R interfaces
Figure 3-137 TS2 (Not for U.S.) - Interfaces (S30810-Q2913-X100, -X300)
Figure 3-138 TS2R (Not for U.S.) - Interfaces (S30810-K2913-Z100, -Z300)
X1
50
2
X2
8
1
To
CUC
TS2
S
2M
interface:
● Wieland termi-
nal (symm. line)
X5
1
● MW8 (RJ48C)
jack (MW line)
X1
50
2
To
CUCR
TS2R
X5
1
S
2M
interface:
● MW8 (RJ48C)
jack (MW line)
