Boards for HiPath 3000

P31003-H3560-S403-54-7620, 09/05

3-356 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual

boards.fm

Options

Interfaces

Figure 3-153 EVM (S30807-Q6945-X) - Interfaces

Spacing bolts

X2

26-pin socket strip

X1 (not used for HiPath 3000)
