Siemens Hipath 5000 - SLMO8 (Not for U.S.), SLMO24

Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-206 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
3.3.17 SLMO8 (Not for U.S.), SLMO24
Introduction
The SLMO8 and SLMO24 (Subscriber Line Module Cost Optimized U
P0/E
) boards provide 8
and 24 connections for connecting optiset E and optiPoint 500 telephones to HiPath 3750, Hi-
Path 3550 and HiPath 3700.
Switches and LEDs
Figure 3-81 SLMO8 (Not for U.S.), SLMO24 (S30810-Q2901-X100, S30810-Q2901-X)
H1 (green)
H2 (red)
LEDs
Lockout switch S1
(position = free,
factory default)
