Peripheral Boards
Front panel
Cable and connector assignment
● For connecting to the SIVAPAC connector on the backplane: Table 3-138
● For connecting to the connector panels with CHAMP jack: Table 3-139
● For connecting to the connector panels using SIPAC 1 SU connectors: Table 3-140
Figure 3-120 TMDID (for U.S. only) (S30810-Q2452-X) - Front Panel
LEDs (green) for displaying the trunk status:
● Trunk circuit 0
● Trunk circuit 1
● Trunk circuit 2
● Trunk circuit 3
● Trunk circuit 4
● Trunk circuit 5
● Trunk circuit 6
● Trunk circuit 7
Switch
Lockout switch
