Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-12 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Overview
HiPath 3550
Note: The HiPath 3550, HiPath 3350, HiPath 3500 and HiPath 3300 peripheral boards must
be firmly inserted into their slots; otherwise contact problems can cause board failure.
ALUM4 S30817-Q935-A Option
ANI4 S30807-Q6917-Axxx Option (for selected countries only)
CBCC S30810-Q2935-A301 Central board
CMA S30807-Q6931-X Central board
CMS S30807-Q6928-X Central board
CUC S30777-Q750-X Central board
EVM S30807-Q6945-X Option
EXM S30817-Q902-B401 Option
EXMNA S30817-Q6923-X Option (for U.S. only)
GEE12 S30817-Q951-Axxx Option (not for U.S.)
GEE16 S30817-Q951-Axxx Option (not for U.S.)
GEE50 S30817-Q951-Axxx Option (not for U.S.)
HOPE S30122-Q7078-X
S30122-Q7079-X
Option (for U.S. only)
HXGS3 S30810-Q2943-X Peripheral board
IMODN S30807-Q6932-X100 Central board
IVMS8 S30122-Q7379-X Peripheral board
LIM S30807-Q6930-X Central board
MMC S30122-X8002-X10 Central board
MPPI S30122-K5380-X200 (not for
U.S.)
S30122-K7275-B
Option
OPAL C39195-A7001-B130 Cable
PDM1 S30807-Q5692-X100 Option
SLA8N S30810-Q2929-X200 Peripheral board (not for U.S.)
SLA16N S30810-Q2929-X100 Peripheral board
SLA24N S30810-Q2929-X Peripheral board
SLC16N S30810-Q2193-X100 Peripheral board (not for U.S.)
SLMO24 S30810-Q2901-X Peripheral board
SLU8 S30817-Q922-A301 Peripheral board
Table 3-2 HiPath 3000 - Overview of All Boards Models Used
Board Part number Function
