boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-143
Boards for HiPath 3000
Peripheral Boards
Figure 3-69 PBXXX (for selected countries only) - Connecting the CAS Cable Using Two
APPCU Adapters
>
The backplane of both PBXXX boards must be closed with the adapter panels pro-
vided (C39165-A7050-C35, Figure 3-67).
Connection cable DIUN2–
PBXXX: C39195-A7700-B7
APPCU adapter (S30807-
K5415-X) on the backplane
CAS cable connections (see
“Assigning both CAS cables” on
page 3-144)
