inst_h3.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
4-53
Installing HiPath 3000
Installing HiPath 3800
Figure 4-30 HiPath 3800 - Connectors and Jacks on the Backplane of the Basic Cabinet
X101
X102
X103
X104
X105
X109
X110
X111
X112
X201
X116
X209
X212
X211
X214
