Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-54 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
Table 4-6 HiPath 3800 - Assignment of Connectors and Jacks on the Backplane of the
Basic Cabinet
Connector Function
X101 – X105 SIVAPAC connector for connecting peripherals:
CABLUs and open-end cables are used for connection to the MDFU-E or to
an external patch panel (see Section 4.2.6.4).
Note: The SIVAPAC connectors can have the following connector panels:
● Connector panels with RJ45 jacks for direct connection of peripherals
(see Section 4.2.6.5).
● For U.S. only: Connector panels with CHAMP jack for direct connection
of peripherals (see Section 4.2.6.6).
● Connector panels each with two SIPAC 1 SU connectors for connecting
an external main distribution frame or external patch panel using CABLUs
(see Section 4.2.6.7).
For selected countries only: PBXXX board: An APPCU adapter (S30807-
K5415-X) is used to connect the CAS cable and the DIUN2 connection cable.
X109 – X112
X116 SIVAPAC connectors for picking up the signals from the REALS board.
CABLUs for connection to the MDFU-E (jumper strip for 25 TW):
● C39195-A7267-A372: 3 m in length, short stripped length for MDFU-E
slots 11-21 (see Figure 4-37)
● C39195-A7267-A373: 3 m in length, long stripped length for MDFU-E
slots 1-10 (see Figure 4-37)
Open-end cable (24 TW) for connection to an external patch panel:
● S30267-Z196-A150: 15 m in length
● S30267-Z196-A250: 25 m in length
● S30267-Z196-A350: 35 m in length
● S30267-Z196-A550: 55 m in length
● S30267-Z196-A950: 95 m in length
X201 68-pin DB68 mini-jack for connecting the cable C39195-Z7611-A10 to the ex-
pansion cabinet (for the DBSAP board)
X209 DC port
X211, X212 AC power
X214 10-pin connection for the ring generator RGMOD (for selected countries only)
