HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-107
Boards for HiPath 3000
Peripheral Boards
Board versions
Eight simultaneous Voice over IP connections are possible per DSP (Digital Signal Processor).
Extension modules
The HXGS3 and HXGR3 boards each have two HGA (HiPath Gateway Accelerator) slots,
which can be used to connect extension modules.
Table 3-43 HXGS3/HXGR3 Board Versions
Board Part number Services DSPs B channels
DSP channels
HXGS3 S30810-Q2943-X Voice and Data 1 8
HXGR3 S30810-K2943-Z Voice and Data 1 8
>
When using the extension module PDM1, the number of DSP channels for HXGS3
and HXGR3 boards can be expanded by eight per board.
Table 3-44 HXGS3/HXGR3 - Extension Modules
Extension
module
Part number Function Notes
PDM1
(PMC DSP
modules)
S30807-Q5692-
X100
Used for expansion for an addi-
tional eight DSP channels.
Maximum of one
PDM1 module possi-
ble.
