inst_h3.fm

P31003-H3560-S403-54-7620, 09/05

HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual

4-183

Installing HiPath 3000

Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300

4.4.3.10 Configuration notes

HiPath 3550: system overview and slots

Restrictions for equipment with IVMP8, IVMS8, TST1 and TS2 boards must be ob-

served.

Figure 4-103 HiPath 3550 - Wall Housing System Overview

Optional boards

PSU

UPS

Cable

duct

Slot levels

CUC
