Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-184 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
Figure 4-104 HiPath 3550 - Slots in the Wall Housing
Figure 4-105 HiPath 3550 - Option Adapter Long (OPAL)
Opt.1
Opt.2
Opt.3Opt.4
Opt.5
Slot 10 (HiPath 3750
Slot 4
Slot 8
Slot 6
Slot 5
Slot 9
Slot 7
V.24
Slot 2Slot 3 CBCC
OPAL
Wall
to MDF
CUC: Connection Unit Com
Slot levels
123456
The CBCC board is connected to
the optional board via a ribbon ca-
ble (OPAL) (see adjacent figure).
