Identifying System Power Requirements
P31003-H3560-S403-54-7620, 09/05
D-2 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
power_calc.fm
HiPath 3800 Board Power Requirement
D.1 HiPath 3800 Board Power Requirement
Table D-1 Nominal Output of the HiPath 3800 Power Supply Unit
Power Supply Unit Part Number Max. Nominal Output in W
5V –48V
LUNA2 S30122-K7686-L1
S30122-K7686-M1
140
1
1 The total max. nominal output at the 5-V and at the –48-V output is 140 W. The 5-V nominal output can vary between 30
and 60 W and the –48-V nominal output can vary between 80 and 110 W. In other words, if 30 W are withdrawn at the 5-
V output, a maximum of 110 W is available at the –48-V output.
>
You must check whether the total power requirement of the boards used and the
connected workpoint clients of a system cabinet exceeds the maximum possible
LUNA2 output. Section D.8 contains a sample calculation.
Table D-2 HiPath 3800 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
CBSAP S30810-Q2314-X 10.0 –
DBSAP S30807-Q6722-X 1.5 –
DIU2U S30810-Q2216-X 5.1 –
DIUN2 S30810-Q2196-X 5.0 –
IVMN8 S30122-H7688-X100 10.0 –
IVMNL S30122-H7688-X 10.0 –
PBXXX S30810-Q6401-X 15,0 –
PDMX S30807-Q5697-X200 3.0 –
REALS S30807-Q6629-X 1.5 –
RGMOD S30124-X5109-X – 14,4
SLCN S30810-Q2193-X300 5.0 –
SLMA S30810-Q2191-C300 1.6 12.0
SLMA2 S30810-Q2246-X 2,1 13,3
SLMA8 S30810-Q2191-C100 0.6 4.0
SLMO2 S30810-Q2168-X10 1.0 1.2
SLMO8 S30810-Q2168-X100 0.4 0.4
