Siemens Hipath 5000 Service Manual

power_calc.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
D-3
Identifying System Power Requirements
HiPath 3800 Board Power Requirement
STMD3 S30810-Q2217-X10 4.0 –
STMI2 S30810-Q2316-X100 16.3 –
TM2LP S30810-Q2159-Xxxx 1.8 –
TMC16 S30810-Q2485-X 1.3 –
TMDID S30810-Q2452-X 2.3 6.6
TMEW2 S30810-Q2292-X100 1.3 3.1
Table D-2 HiPath 3800 Board Power Requirement
Board or Component Part Number Net Power Requirement in
W
5V –48V
