Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-378 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Options
3.4.15 STBG4 (For France Only)
Introduction
This current-limiting board is for connecting loop start trunks in France (HiPath 3550 and HiPath
3350). It includes the current-limiting components and surge-protection elements required by
law.
No options bus lines are needed.
The slot X3 wiring is polarized.
The STBG4 channel is looped between TLA and the trunk.
Figure 3-168 STBG4 (For France Only) - Interfaces (S30817-Q934-A)
Table 3-175 STBG4 (For France Only) - Contact Assignment
Contact Connector X3 Connector X4
1 Not used AL 1
2 BL 1 BL 1
3AN 1 AL 2
4 BL 2 BL 2
5AN 2 AL 3
6 BL 3 BL 3
7AN 3 AL 4
8 BL 4 BL 4
9AN 4 –
10 Not used –
CB side
Board side
STBG4
TLA
Tr unk
MDF
X1
X2
X3
X4
1
10
1
8
