Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-10 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
4.2.3.3.3 Stacking Two Cabinets
Procedure
7
Caution
To guarantee sufficient ventilation for the system cabinets, comply with the following
requirements:
● The basic cabinet must be set up as the bottom cabinet.
● Allow a minimum of 50 mm clearance between the base of the cabinet and the
floor, and between basic and expansion cabinets.
Step Activity
1. Place the system cabinet in the installation site and make sure that it is level and
stable.
2. Check that the space between the base of the basic cabinet and the ground is at
least 50 mm.
3. If necessary, set up the basic cabinet in the following way:
● Unscrew lock nut (Figure 4-1, A) on one of the cabinet feet using an open-end
wrench (wrench size = 13 mm).
● Adjust the height of the cabinet foot by turning the screw nut (Figure 4-1, B)
so that the cabinet is steady and the minimum clearance is observed.
● Fix the cabinet foot in position by tightening the lock nut (Figure 4-1, A).
4. Place the expansion cabinet on top of the basic cabinet.
The cabinet feet have indents. When placing the expansion cabinet on top of the
basic cabinet, ensure that these indents are sitting precisely on top of the screw
heads in the four corners of the basic cabinet (Figure 4-2).
5. Check that the space between the base of the basic cabinet and the ground is at
least 50 mm.
6. If necessary, set up the expansion cabinet as described in Step 3.
To Next Page
