Workpoint Clients
P31003-H3560-S403-54-7620, 09/05
10-28 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
wclient.fm
optiPoint 500
Table 10-2 Floating contacts on the optiPoint acoustic adapter
Pin Assign-
ment
Notes
1Free
2 "Busy" con-
tact
Signals active telephone states:
handset lifted
Loudspeaker activated or headset active
These states can be displayed, for example, on external signaling equip-
ment (LED, relay, etc.) The signaling equipment must have its own power
supply.
The contact can be loaded with up to 5 W at 24 Vac or 60 Vdc.
3
4 "Call" con-
tact
Signals the call receipt state.
This can be used, for example, to control a secondary bell.
The contact can be loaded with up to 5 W at 24 Vac or 60 Vdc.
5
6Free
