Peripheral Boards
EPSU2 external power supply
The EPSU2 AC/DC converter is an external power supply unit for use when the UPSC-D is un-
able to provide sufficient power for the base stations and telephones at the HiPath 3550.
The external power supply EPSU2 comes in two versions:
● S30122-K7221-X1 - This version is always supplied with four built-in batteries. These bat-
teries guarantee approx. 30 minutes of bridging time in the event of a power failure.
● S30122-K7221-X2 - This version is supplied without batteries. To use this model’s uninter-
ruptible power supply function, four batteries must be ordered separately and installed.
>
The new EPSU2 model S30122-K7221-X2 is designed to replace S30122-
K7221-X1.
Differences between the two models are indicated at the appropriate point in the
following description.
