boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-123
Boards for HiPath 3000
Peripheral Boards
Lockout switch settings
● Pressed = free (default)
● Not pressed = locked: existing connections remain active, new connections are locked.
– The yellow LED lights up when all connections are ended and the board is effectively
locked.
– The yellow LED flashes when a lockout request is entered (via lockout switch or soft-
ware) but at least one call is still active.
To reset the board to the default state, activate the lockout switch four times (off-on-off-on) dur-
ing the LED test. This action cancels the LED test and both LEDs flash for approximately
five seconds in confirmation.
LED statuses and their meanings
Table 3-49 IVMNL/IVMN8 - LED Statuses
LED
Red
Green
LED
Meaning Action
During Startup and Initialization
Off Off 1 Boot procedure (lasts approx. 8 -
12 s)
On On 2 LED test (lasts approx. 10 s)
On Off 3 Lockout switch state signaling by
red LED (lasts approx. 5 s):
● blocked = On
● free = Off
Possibly check if board was de-
activated using HiPath 3000
Manager E or lockout switch.
Off
Flashing
(500/
500 ms)
Off 4 Hard disk test, start of the applica-
tion (depending on hard disk sta-
tus, lasts approx. 3 - 8 minutes)
Off On 5a Standby mode after successful
boot
On Off 5b Board locked or board error oc-
curred
Check whether board was deacti-
vated using HiPath 3000 Manag-
er E or lockout switch.
During Operation
Off On Idle (no call)
Off Flashing
(500/
500 ms)
At least one active port (call)
To Next Page
