Workpoint Clients
optiPoint Accessories
10.7.1.2 AC Adapter for optiPoint 410 / optiPoint 410 S and optiPoint 420 / optiPoint
420 S
The AC adapter features two MW6 connectors. Power is supplied to a telephone via the left
board marked "Digital".
Variants
● AC adapter, Euro: C39280-Z4-C510
● AC adapter, UK: C39280-Z4-C512
● AC adapter, 110 V USA: C39280-Z4-C511
Technical Specifications
Technical Specifications AC adapter, Euro:
C39280-Z4-C510
AC adapter, UK:
C39280-Z4-C512
AC adapter, 110 V
USA:
C39280-Z4-C511
Line voltage 230 VAC 230 VAC 120 VAC
Line frequency 50 Hz 50 Hz 60 Hz
Output voltage max. 43 VDC,
min. 30 VDC
max. 43 VDC,
min. 30 VDC
max. 43 VDC,
min. 30 VDC
Output current 480 mA 480 mA 480 mA
