HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-15
Boards for HiPath 3000
Overview
STLSX2 S30810-Q2944-X100 Peripheral board
STLSX4 S30810-Q2944-X Peripheral board
STRB S30817-Q932-A Option
TLA2 S30817-Q923-Bxxx Peripheral board (not for U.S.)
TLA4 S30817-Q923-Axxx Peripheral board (not for U.S.)
TLA8 S30817-Q926-Axxx Peripheral board (not for U.S.)
TMGL4 S30810-Q2918-X Peripheral board (for U.S. only)
TMQ4 S30810-Q2917-X Peripheral board (for U.S. only)
UAM S30122-X7217-X Option (not for U.S.)
UPSC-D S30122-K5660-M300 Central board
V24/1 S30807-Q6916-X100 Option (not for U.S.)
4SLA S30810-Q2923-X200 Peripheral board (not for U.S.)
8SLA S30810-Q2923-X100 Peripheral board
16SLA S30810-Q2923-X Peripheral board (not for U.S.)
Table 3-2 HiPath 3000 - Overview of All Boards Models Used
Board Part number Function
