IP Fundamentals
IP Network Requirements
Information on the QoS procedures used for HG 1500 can be found in the HG 1500 Adminis-
tration Manual.
Table 13-2 Possible QoS Settings
Traffic type DiffServ
Code Point
802.1p field
(Priority 0 (= lowest) – 7 (=
highest)
Traffic class
Voice payload (RTP/RTCP) AF12
(001100)
6 Guaranteed service
Data payload (fax gateway) AF11
(001010)
6 Guaranteed service
Signaling (H.225, H.245 and
real-time application signaling)
AF21
(010010)
5 Controlled Load
All other traffic types DE (000000) 0 Best effort
