Boards for HiPath 3000
Peripheral Boards
Front panel
Figure 3-39 CSAPE (S30807-U6630-X)
Fan drawer
AC power supply unit ACPCI
Slide-in shelves for the Embed-
ded Application Server EAS
Fan drawer
