Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-94 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
Front panel
1 13 b-wire (R), transmit blu/wht
15 41 a-wire (T), receive wht/ora
8 16 b-wire (R), receive ora/wht
Figure 3-42 DIU2U (for U.S. only) - Front Panel (S30810-Q2216-X)
Table 3-32 DIU2U (for U.S. only) - adapter cable assignment (C39195-A7269-B625)
15-pin Sub-D
connector
pin
50-pin Amphenol
connector
pin
Function Color code
Two LEDs indicating the board status:
● LED (green)
● LED (red)
Interface 2
Interface 1
