boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-97
Boards for HiPath 3000
Peripheral Boards
Front panel
Figure 3-43 DIUN2 - Front Panel (S30810-Q2196-X)
Two LEDs indicating the board status:
● LED (green)
● LED (red)
Interface 2
Interface 1
