Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-128 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
Assignment of the RJ45 jack X3
The Ethernet (10/100BaseT) interface is accessed via the 8-pin RJ45 jack X3. The signals are
output simultaneously at the printed circuit connector X2.
Table 3-51 IVMP8 and IVMP8R (not for U.S) - Assignment of the RJ45 Jack X3 (LAN Con-
nector)
RJ45 Jack X3
Pin
Signal Description Printed Circuit Con-
nector X2
Pin
1Tx+Transmit+ 1
2Tx–Transmit– 3
3 Rx + Receive + 7
4 – Not used
5 – Not used
6 Rx – Receive – 9
7 – Not used
8 – Not used
