Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-156 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
SLC16N system configuration
For information on the maximum possible system configuration of HiPath Cordless Office with
the SLC16N boards see Table 11-1.
SLC16N board distribution in HiPath 3750 and HiPath 3700 cabinets
You can install up to four SLC16N boards in HiPath 3750 and HiPath 3700. Please note the
following when distributing the boards in the individual cabinets:
● Basic cabinet (BC)
Up to two SLC16s or SLC16Ns can be installed in the basic cabinet. Sixteen BS3/1s or
eight BS2/2s and BS3/3s can also be connected.
● Expansion cabinets EC1 and EC2
The four SLC16s or SLC16Ns can be installed in a single expansion cabinet. And up to
sixteen BS3/1s or eight BS2/2s and BS3/3s can be connected per SLC16N.
To avoid overloading the power supply when operating four SLC16s or SLC16Ns in a single
expansion cabinet, you must not install any other peripheral boards in this cabinet.
>
To guarantee uninterrupted operation of HiPath 3750 and HiPath 3700, the SLC16N
should not be installed with a second SLC16N, an SLMO24 or a TS2 on a PCM seg-
ment. This condition must always be observed.
For information on PCM segment distribution, see Page 4-158.
