Boards for HiPath 3000
Peripheral Boards
Assignments for the two TMCAS cables for HiPath 3750, HiPath 3700, and HiPath 3550
You can use one of the following two cables to connect the network terminator NT, multiplexer
MUX, or modem to the TMCAS board:
● symmetric line (120 ohms)
● coaxial line (75 ohms)
Table 3-135 Assignment of the TMCAS Cable C39195-A9700-B512
SU connector Xx8, pin Function Color code
2 a-wire (T), receive grn
22 b-wire (R), receive blk
6 a-wire (T), transmit red
26 b-wire (R), transmit blk
Table 3-136 Assignment of the TMCAS Cable C39195-A9700-B514
SU connector Xx8, pin Function Wire
2 a-wire (T), receive BNC shield, cable 1
22 b-wire (R), receive BNC signal, cable 1
6 a-wire (T), transmit BNC shield, cable 2
26 b-wire (R), transmit BNC signal, cable 2
