Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-310 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
Contact assignment
Table 3-147 TMGL4R (for U.S. only) - Contact Assignment
Port X3 Pin
(To GEE)
X4 Pin
(To trunks 1-4)
X5 Pin
(To ANI4R)
Signal
1 3 12 3 b-wire (ring), trunk 1
2 13 2 a-wire (tip), trunk 1
2 5 22 5 b-wire (ring), trunk 2
4 23 4 a-wire (tip), trunk 2
3 7 32 7 b-wire (ring), trunk 3
6 33 6 a-wire (tip), trunk 3
4 9 42 9 b-wire (ring), trunk 4
8 43 8 a-wire (tip), trunk 4
– 10 – 10 Call charging module
assignment (GMZ)
