Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-312 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
LED statuses and their meanings
Cable and connector assignment (backplane, MDF)
Table 3-148 TMGL8 (for U.S. only) - LED Statuses
Status of LEDs 1–8 Meaning
Off Channel is idle, ready to use
On Channel is seized
Flashing Channel is deactivated
Winking System software test in progress
Table 3-149 TMGL8 (for U.S. only) - Assignment (SU Xx8)
#a-Wire
(Tip)
b-Wire
(Ring)
SU connector
(backplane)
TMGL8 CHAMP jack, MDF Notes
Xx8
1 wht/blu 19 1a Port 1 1 1 a/b-wire
blu/wht 39 1b 26 1 b/a-wire
2 wht/ora 38 2a Port 2 2 2 a/b-wire
ora/wht 48 2b 27 2 b/a-wire
3 wht/grn 27 3a Port 3 3 3 a/b-wire
grn/wht 47 3b 28 3 b/a-wire
4 wht/brn 16 4a Port 4 4 4 a/b-wire
brn/wht 46 4b 29 4 b/a-wire
5 wht/gry 05 5a Port 5 5 5 a/b-wire
gry/wht 45 5b 30 5 b/a-wire
6 red/blu 14 6a Port 6 6 6 a/b-wire
blu/red 44 6b 31 6 b/a-wire
7 red/ora 23 7a Port 7 7 7 a/b-wire
ora/red 43 7b 32 7 b/a-wire
8 red/grn 32 8a Port 8 8 8 a/b-wire
grn/red 42 8b 33 8 b/a-wire
No other wires used.
