HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-317
Boards for HiPath 3000
Peripheral Boards
Contact assignment
Note: Pinouts shown are at the board itself. The main distribution frame cable (MDF cable) sup-
plied reverses the signal order before the MDF.
Table 3-152 TMQ4 (for U.S. only) - Contact Assignment
Contact Connector X2 Port Contact Connector X2 Port
1 b-wire (ring), trunk 1 1 5 b-wire (ring), trunk 3
3
2 a-wire (tip), trunk 1 6 a-wire (tip), trunk 3
3 b-wire (ring), trunk 2 2 7 b-wire (ring), trunk 4
4
4 a-wire (tip), trunk 2 8 a-wire (tip), trunk 4
