System Data
HiPath 3000
Dimensions
Figure 2-2 HiPath 3750 Dimensions
Cable duct
Depth of the MDFU or MDFU-E: 126 mm
Depth of system cabinet: 390 mm
EC1
BC
EC2
MDFU
MDFU-E
MDFU
MDFU
approx. 328 mm
approx.
approx.
approx. 980 mm
approx. 670 mm
