Siemens Hipath 5000 Service Manual

boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-329
Boards for HiPath 3000
Peripheral Boards
Contact assignment
Table 3-157 TST1 (For U.S. Only) - Contact Assignment
Contact X2 Contact X2
1 b-wire (ring), receive 5 a-wire (tip), transmit
2 a-wire (tip), receive 6 not connected
3 not connected 7 not connected
4 b-wire (ring), transmit 8 not connected
