boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-343
Boards for HiPath 3000
Options
ALUM module block diagram
Figure 3-146 ALUM4 - Basic Structure
K1-B
HiPath 3550
HiPath 3350
K2-B
R1 T1
Relay
K1-C
K2-C
AE1 BE1
Relay
Tr un k
board
Station
board
Connector X6
TB1
TA1
AT1 (R1)
BT1 (T1)
Connector
X3
Tr un k
ALUM
Connector
X4
Analog telephone
