boards.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
3-351
Boards for HiPath 3000
Options
Contact assignment
Table 3-168 ANI4R (for selected countries only) - Contact Assignment
X3 Pin Signal X3 Pin Signal
1 – 6 a-wire (tip), trunk 3
2 a-wire (tip), trunk 1 7 b-wire (ring), trunk 3
3 b-wire (ring), trunk 1 8 a-wire (tip), trunk 4
4 a-wire (tip), trunk 2 9 b-wire (ring), trunk 4
5 b-wire (ring), trunk 2 10 Call charging module assignment
(GMZ)
