Boards for HiPath 3000
Options
STRB and STRBR board relay and sensor functions
Figure 3-171 STRB and STRBR Board Relay and Sensor Functions
STRB or STRBR
K1.21
K1.22
K1.23
K1.11
K1.12
K1.13
Relay
+12 VI+12 V
OPTKP1
To system
Short the wires to activate the
sensor.
Sensor
