Installing HiPath 3750, HiPath 3700
Laying the Connecting Cables
To lay the connecting cables between the two cabinets, you can cut out the pre-stamped re-
cesses in the bottom of EC1 and the top of the BC with a pair of diagonal cutting pliers and
break them out with a pair of flat-nosed pliers.
7
Warning
Be careful when breaking out the recesses. Remove any sharp edges and corners.
