inst_h3.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
4-123
Installing HiPath 3000
Installing HiPath 3750, HiPath 3700
Color Codes for the Open-End Cable
Table 4-13 Color Codes for the Open-End Cable
Color
group
Pair a-Wire
(Tip)
b-Wire
(Ring)
Color
group
Pair a-Wire
(Tip)
b-Wire
(Ring)
1 1 wht/blu 3 11 blk/blu
blu/wht blu/blk
2 wht/ora 12 blk/ora
ora/wht ora/blk
3 wht/grn 13 blk/grn
grn/wht grn/blk
4 wht/brn 14 blk/brn
brn/wht brn/blk
5 wht/gry 15 blk/gry
gry/wht gry/blk
2 6 red/blu 4 16 yel/blu
blu/red blu/yel
7red/ora
ora/red
8red/grn
grn/red
9red/brn
brn/red
10 red/gry
gry/red
To Next Page
