Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-144 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3750, HiPath 3700
4.3.4.7.2 Connecting the Patch Panel and Backplane (in the 19-Inch Cabinet)
Introduction
Set up the connection between the patch panel and system using CABLUs (prefabricated ca-
bling units) with the following characteristics:
● System side: SIPAC 1 SU jack
● Cable: 16 x 2 x 0.4 (the standard cable length is 2 m)
● Patch panel side:
– Not for U.S.: Open-end cable (for STMD8) or SIVAPAC socket connectors (for all other
boards)
– For U.S. only: ---
Not for U.S.: CABLUs for the slots containing peripheral boards
If Then
Assignment
with
SLMO8
1
,
SLMO24,
SLA8N
1
,
SLA16N
1
or
SLA24N
Route 16 TW to the patch panel (S30807-K6143-X) via SU Xx8 and 8 TW via
SU Xx9 using a standard cable (with 16 TW) for each connection. Connect
both cables (= 1 CABLU with SU jacks labeled 8 and 9) to the same SIVAPAC
socket terminal strip (25 TW).
Part number for CABLU with 24 TW:
● S30267-Z363-A20: 2 m in length
Assignment
with
STMD8
You need a special S
0
patch panel (C39104-Z7001-B3) for this. The 16 TW
are routed to (and manually laid at) the S
0
patch panel via SU Xx8 (back-
plane) using an open-end cable.
Part numbers for open-end cable:
● S30267-Z192-A60: 6 m in length
● S30267-Z192-A100: 10 m in length
● S30267-Z192-A200: 20 m in length
Assignment
with
TMS2
S
2M
connections are not set up via a patch panel.
An adapter (SIPAC 1 SU jack - 8-pin MW8 (RJ48C) jack, Figure 4-86) is con-
nected directly to the SU Xx9 backplane connector. You can use a special ca-
ble (see Section 3.3.42, “TMS2 (Not for U.S.)”) to create a direct connection
to the NT or networked system.
To Next Page
