sysdat.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
2-37
System Data
Dynamic Configuration Rules
Performance requirement for the Media Gateway (= Gateway HG 1500)
Calculation of the dynamic performance requirement for the DSL connection on the basis of the
highest throughput rates (upstream = 192 Kbps = (192 x 1000) / 8 bps = 24000 bps, Down-
stream = 2048 Kbps = (2048 x 1000) / 8 bps = 256000 bps). The following formulae apply for
1400 byte packet length:
The specified performance requirement of 738.0 points is below the 980 total performance
points that the HXGM3 board can provide. The configuration is feasible.
Upstream: Downstream:
24000 bps 256000 bps
= 17 packets/sec = 183 packets/sec
1400 bytes/packet 1400 bytes/packet
Function Resource require-
ment
(credit point)
Data transfer (addi-
tional feature: En-
hanced B Channels
disabled over WBM.)
DSL connection (without encryption with 1400 bytes packet length,
performance requirement (score) = 96 for 100 packets/sec):
17 packets/sec upstream (192 kbps) 17 x (96 / 100) = 16.32
183 packets/sec downstream (2048 kbps) 183 x (96 / 100) =
175.68
Payload (additional
feature: Enhanced B
Channels disabled
over WBM.)
Voice gateway channel over LAN interface 1 without encryption:
14 x G.711 (received: 20 msec/sent:
20 msec)
14 x 39.0 = 546.0
Total = 738.0
