HiPath 5000 Startup and Administration
P31003-H3560-S403-54-7620, 09/05
6-12 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
start_h5.fm
Installation Requirements
HiPath Software
Manager
possible possible possible possible possible possible
DLS
3
possible possible possible possible possible possible
HiPath Manager
PCM V2.0
possible possible possible possible possible possible
HiPath FM possible possible possible possible possible possible
Teledata Office
3
possible possible possible possible possible possible
HPCO including Hi-
Path Xpressions
3
up to 248 stations
possible
up to 248
stations
possible
up to 248
stations
possible
up to 248
stations
possible
not pos-
sible
not pos-
sible
HPCO
3
1 to 32 agents
possible
1 to 32
agents
possible
1 to 32
agents
possible
1 to 32
agents
possible
not pos-
sible
not pos-
sible
1 Every HiPath 3000 gateway, every survivable media gateway and every HiPath ComScendo service counts as a node.
2 Networks are currently released with up to 32 nodes. Larger configurations can be released on a project-specific basis.
3 We do not recommend installing DLS, Teledata Office, HPCO (including HiPath Xpressions), and HiPath ComScendo Ser-
vice together on a PC. Real-time operation of the HiPath ComScendo Service cannot be guaranteed if the lion’s share of
processor resources is required for DLS, Teledata Office, HPCO (including HiPath Xpressions). Software updates, call
charge data queries, statistics, etc. must be performed during off-peak hours when few or no calls are underway.
If the customer is unwilling to accept restrictions, HiPath ComScendo Service must be installed on a separate PC.
Table 6-4 Prerequisites for a Single-PC Solution
Upgrade V4.0 to
V6.0
1-node system
(1 GHz CPU)
2 nodes
1
(3 GHz
CPU)
3 - 6
nodes
1
(3 GHz
CPU)
7 - 16
nodes
1
(3 GHz
CPU)
17 - 32
nodes
1
(3 GHz
CPU)
33 - 64
2
nodes
1
(3 GHz
CPU)
