Workpoint Clients
P31003-H3560-S403-54-7620, 09/05
10-60 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
wclient.fm
optiPoint 410 / optipoint 410 S and optiPoint 420 / optiPoint 420 S
Table 10-6 optiPoint 410, optiPoint 420, optiPoint 410 S, optiPoint 420 S - Description of
Connections
No. Connection
1 Ethernet (10/100BaseT) interface (self-configuring) for the LAN
2 Handset
3 Local power supply (optional)
1
1 No local power supply is required if power is provided via the Ethernet cable (Power over LAN).
4 Add-on device
5 Ethernet (10/100BaseT) interface (self-configuring) for the PC
6 Headset (121 TR 9-5)
7 Adapter 1
8 Adapter 2
9 USB interface
