cordless.fm
P31003-H3560-S403-54-7620, 09/05
HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
11-11
HiPath Cordless Office
Multi-SLC and System-Wide Networking
Networked HiPath 3000 systems feature
● max. 64 networked systems
● accessible using a shared station number (roaming among the systems/nodes)
● call interruption when changing between systems/nodes
Figure 11-3 Example of a Cordless Extension Connection in Networked Systems
BS
SLC16N
BS
CorNet NQ
Home SLC16N
SLC16N no. = 1
Station no. = 124
Current-location
SLC16N
SLC16N no. = 11
Station no. = 128
HiPath 3750
Node ID = 1
HiPath 3550
Node ID = 2
Extension
connection
BS
SLC16N
BS
SLC16N no. = 2
Station no. = 141
BS
SLC16B
BS
BS = BS2/2, BS3/1 or
BS3/3
A CorNet NQ connection is possible using S
0
or S
2M
lines or IP networking (see HG 1500 Administration
Manual).
