12-25
Service
Guided Maintenance
For ISDN boards, the status of the reference clock is displayed:
● No reference clock
● Reference clock for clock generator is created.
When viewing the board status using the HiPath 3000 Manager E, all peripheral boards inte-
grated into the system are presented in a table. The status display is updated every 3 seconds.
With Assistant T, you can only view the status of one board at a time. You can also update the
status display by pressing a key.
You cannot perform additional activities with the HiPath 3000 Manager E and Assistant T while
viewing the status of a board.
HiPath 3750 and HiPath 3700: LEDs on peripheral boards
All peripheral boards are equipped with LEDs for displaying the status of a board or port. Infor-
mation on the meaning of the individual LED statuses can be found in the descriptions of indi-
vidual boards in Chapter 3.
Table 12-4 HiPath 3000 Manager E - Example of Status Display of Peripheral Boards
Slot Board not
inserted
Defective Blocked Free Res. Clock
source
1STLS2 X X X
2SLU8 X
3SLA4 X X
4TLA8 X
5
6
7TS2 X X
8 16SLA X
9
10 SLMO24 X
