6Ifyouwanttocheckthecommunicationparameters,selectInspectPort.
Note
Youcannotmakeanychangeshere.Tochangethecommunicationparameters,use
theI/OSetuppage.TheI/OSetuppageislocatedintheInstallationandOutput
dialogboxes.
7IfyouwanttocheckthattheperipheralsystemistransmittingdatatotheES80,
selectMonitor.
ThePortMonitordialogboxprovidesonetextboxforincomingmessages(Rx
Data),andoneforoutgoingmessages(TxData).Usetheseboxesandyour
knowledgeofthedatacommunicationtoinvestigatethedatagrams.ThePort
Monitordialogboxisatoolfordebuggingpurposes.Itisneitherrequirednor
intendedfornormaloperationoftheES80.
8Typeacustomnametoidentifytheinterfaceinotherdialogboxes.
9Selectwhichdatagram(s)youwanttoimportfromtheperipheraldevice.
WhenyouselectsensortypeAnnotation,onlyonedatagramcanbeselected.
10DonotspecifyadedicatedTalkerID.
11SelectAddtosavethenewdeviceinterfaceyouhavedened.
ThedeviceinterfaceisaddedtotheInstalledSensorslistontheSensorInstallation
page.ItisnotnecessarytousetheSensorCongurationpagetosetupaprioritylist.
12SelectApplyandthenClosetosavealltheparametersandclosetheInstallation
dialogbox.
ConnectingacatchmonitoringsystemtoaserialorLAN
(Ethernet)port
AcatchmonitoringsystemcanbeconnectedtotheES80.Theconnectionismadeusing
aserialorLAN(Ethernet)portontheProcessorUnit.Foranysensorinterfacetowork,
thecommunicationparametersmustbesetupcorrectly.
Prerequisites
Thisprocedureassumesthat:
•YouhaveavacantinterfaceportonyourProcessorUnit.
•YouarefamiliarwithNMEAandotherrelevantdatagramformats.
•Youknowhowtosetuptheparametersforserialandlocalareanetwork(LAN)
communication.
•Theinterfaceportissetupwiththecorrectcommunicationparameters.
