Accessingtheechodatalestodelete,moveorcopythem
TherawdatarecordingfunctionprovidedbytheES80allowsyoutosaveechodata
usingthe*.rawformat.YoucansavetotheProcessorUnitharddisk,orontoanexternal
disk.Youcankeeptherecordedlesforscienticstudies,futurereferences,orfor
trainingpurposes.Thedatalescanbecopiedormovedtootherrecordablemedia,
ortoanothercomputeronthenetwork.
Prerequisites
ItisassumedthatyouarefamiliarwiththeMicrosoft
®
operatingsystemutilitiesfor
lehandling.
Youneedadatastoragedevice.ThisistypicallyalargecapacityUSBashdriveora
smallportableharddisk.YoucanalsoconnecttheProcessorUnittoanetwork,and
copythelestoaserver.
Procedure
1Prepareadatastoragedevice.
2ObservetheScreenCapturestabatthebottomoftheES80presentation.
3SelecttheScreenCapturestabtoopenthescreencapturebrowser.
4Inthebrowser,selectOpenImageFoldertoopentheoperatingsystemfolder.
5Inthelemanagerutility,locatethefolderyoudenedontheFileSetuppage.
6Usethefunctionalityprovidedbytheoperatingsystemtodeletetheles,orto
copyormovethemtothestoragedevice.
7Closethelemanagerutility.
8ToresumenormalES80operation,selectanyothertabonthebottombar.
SimradES80ReferenceManual

Simrad ES80 Specifications

General

Operating Temperature	-15°C to +55°C
Type	Echosounder
Transceiver	External
Applications	Fisheries research, commercial fishing
Depth Range	Up to 3000 meters
Interface	Ethernet, NMEA 2000
Frequency Range	18 kHz, 38 kHz, 70 kHz, 120 kHz, 200 kHz, 333 kHz
