406273/C

339

Setupmenu:Functionsanddialogboxes

TheSetupmenuprovidesbasicfunctionsrelatedtotheES80installationparametersand

itscommunicationwithperipheralsystems.

Howtoopen

SelecttheSetupicon.

TheiconislocatedundertheMainmenu.Selectthe

icononemoretimetoclosethemenu.

Topics

Environmentdialogbox,page340

WaterColumnpage,page340

ManualAnnotationdialogbox,page342

FishSelectdialogbox,page343

CalculationIntervaldialogbox,page344

Installationdialogbox,page346

TransducerInstallationpage,page348

Transceiverpages,page352

SensorInstallationpage,page363

SensorCongurationpage,page369

I/OSetuppage,page371

Synchronizationpage,page375

Unitspage,page378

Trawlpage,page380

Annotationspage,page382

SoftwareLicensepage,page384

Outputdialogbox,page386

FileSetuppage,page388

DepthOutputpage,page391

RelayOutputpage,page395

OlexOutputpage,page397

Languagefunction,page399

Functionsanddialogboxes
