Simrad ES80 User Manual

116
406273/C
7SelectOKtosavetheselectedsettingsandclosethedialogbox.
Selectingthehorizontalscaleintheechograms
Thehorizontalscalecontrolshow"fast"theechogramsmovefromrighttowardsleft
acrosstheES80presentation.YoucanchangethehorizontalscaleontheHorizontalAxis
pageintheEchogramdialogbox.
Context
TheechogramstravelsfromrighttowardsleftacrosstheES80presentation.Onthe
HorizontalAxispageyoucanchoosethehorizontalscaleoftheechogram.Thiscontrols
the"speed"oftheechogram.
•Distance
Thehorizontalscaleoftheechogramisbasedonsaileddistance.Selectresolution
andunit.
•Time
Thehorizontalscaleoftheechogramisbasedontime.Selectresolutionandunit.
•Ping
Thehorizontalscaleoftheechogramisbasedonthenumberoftransmissions
("pings")made.SelectViewSizetospecifythatthenumberofhorizontalpixelsshall
denethenumberofdisplayedhorizontalpingsusingonepingperpixel.
•Speed
Thehorizontalscaleoftheechogramisbasedontherelativespeedyouchoose.
Selectspeedwiththeruler.
Note
Thisisavisualenhancement.ItdoesnothaveanyeffectontheES80performance.
Procedure
1Clickonceintheechogramviewthatyouwishtochange.
Thiswillmaketheview"active".Athickborderisplacedontheselectedview
tovisualizethis.
2OpentheActivemenu.
3SelectEchogram.
ObservethattheEchogramdialogboxopens.
4OntheleftsideoftheEchogramdialogbox,selectHorizontalAxistoopenthepage.
5Selectthehorizontalscaleyouwishtouse.
SimradES80ReferenceManual
