Simrad ES80 User Manual

406273/C
59
SettinguptheES80Widebandshnding
echosounderforthersttime
Topics
Settingupsummary,page59
Adjustingthescreenresolution,page61
InstallingtheES80operationalsoftware,page62
DeningtheIPaddressontheProcessorUnitnetworkadapterforcommunicationwith
theWideBandTransceiver(WBT),page63
TurningontheES80toPassivemode,page64
Obtainingandinstallingthesoftwarelicense,page65
Installingoneormoretransducers,page67
Installingtransceiverchannels,page69
DeningtheserialandEthernet(LAN)portparameters,page71
Settinguptheinputfromanavigationsystem(GPS),page73
Settingupsummary
BeforeanewES80Widebandshndingechosoundercanbeputtouse,itmustbe
setupforoperation.
Prerequisites
•TheES80Widebandshndingechosoundersystemunitshaveallbeeinstalled
accordingtotheinstructionsintheES80Installationmanual.
•Allcableshavebeenconnectedandveried.
•Allsystemunitshavebeeninspected.
•TheES80operationalsoftwareisavailable.
•TheES80softwarelicenseisavailable.
Caution
YoumustneversettheES80intonormaloperationwhentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair.
Procedure
1Dothefollowingpreparations.
Gettingstarted
